High Efficiency Underground Cable Installation Tools Cable Hauling Machine

Name: High Efficiency Underground Cable Installation Tools Cable Hauling Machine
Brand: SHENHONG
Price: 1 USD

Wholesale High Efficiency Underground Cable Installation Tools Cable Hauling Machine from china suppliers

Brand Name : SHENHONG

Model Number : DSJ-180

Certification : ISO

Place of Origin : Jiangsu, China

MOQ : 1sets

Price : negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100sets per month

Delivery Time : 7-10 days after payment

Packaging Details : Standard export wooden case

Usage : Cable pulling

Type : Cable Feeder

Line pulling(KGS) : 900

Electric motor : 1.5KW × 2

Weight(KGS) : 180 - 200

Oversize dimension(mm) : 1020*590*400

Contact Now

High Efficiency Underground Cable Installation Tools Cable Hauling Machine

Application

DSJ cable feeders push the cable in the cable duct which reduces the tension on the cable as well as reducing the need of pulling force of the cbale winch.The feeder should be put before a bend in the cable duct.A carterpillar band transports the cable,the belt id made of steel chain with special vulcanised rubber cushions to drive the feeder.

Features

Using this kind of this device changes the manual transmission cable. It can save a lot of labor, improve working conditions,

reduce labor intensity, improve work efficiency and ensure the safety.

Technical Data

Model Type	DSJ-150	DSJ-180
Line pulling(KGS)	700	900
Pulling Speed(m/min)	8	6
Electric motor	1.1KW *2	1.5KW * 2
Oversize dimension	950500400	1020590400
Weight(KGS)	150	180-200
Cable diameter	Φ30 - 180 mm	Φ30 - 200 mm
Transimission	I=45	I=60
Rubber sheet thickness	25mm	25mm
